1FK7063-5AF71-1PA0 SİEMENS
****spare part**** SIMOTICS S synchronous servo motor 1FK7 Compact 11 Nm, 100K 3000 rpm, 2.29 kW naturally cooled IM B5 (IM V1, IM V3) power/signal connector plug rotatable by 270° RESOLVER 2-POLE (RESOLVER P=1) WITH DRIVE-CLIQ INTERFACE; SHAFT WITH FITTED KEY, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP64
- Kategori :: Siemens, Sürücü/motor siemens, Sinamics
- Ürün Kodu :: 1FK7063-5AF71-1PA0 SİEMENS
- Etiketler :: 1FK7063-5AF71-1PA0 , SİEMENS 5AF71 , SINAMICS , SİNAMİKS , SİEMENS MOTOR , SİEMENS , 1FK7063-5AF71-1PA0 SİEMENS , 1FK7063-5AF71 MOTOR , SÜRÜCÜ MOTOR SİEMENS
- Stok :: Stokta Var
****spare part**** SIMOTICS S synchronous servo motor 1FK7 Compact 11 Nm, 100K 3000 rpm, 2.29 kW naturally cooled IM B5 (IM V1, IM V3) power/signal connector plug rotatable by 270° RESOLVER 2-POLE (RESOLVER P=1) WITH DRIVE-CLIQ INTERFACE; SHAFT WITH FITTED KEY, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP64
Product | ||
Article Number (Market Facing Number) | 1FK7063-5AF71-1PA0 | |
Product Description | ****spare part**** SIMOTICS S synchronous servo motor 1FK7 Compact 11 Nm, 100K 3000 rpm, 2.29 kW naturally cooled IM B5 (IM V1, IM V3) power/signal connector plug rotatable by 270° RESOLVER 2-POLE (RESOLVER P=1) WITH DRIVE-CLIQ INTERFACE; SHAFT WITH FITTED KEY, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP64 | |
Product family | Not available | |
Product Lifecycle (PLM) | PM410:Product cancellation | |
PLM Effective Date | Product is cancelled since: 01.10.2019 | |
Notes |
Sucessor:successor product is 1FK7 Generation 2Successor product is 1FK7 Generation 2
This product is a Spare Part, please visit the Spares & Service section for more information
If you need assistance please contact our local Siemens office
|
|
Price data | ||
Region Specific PriceGroup / Headquarter Price Group | S60 / 7A6 | |
List Price | Show prices | |
Customer Price | Show prices | |
Surcharge for Raw Materials | None | |
Metal Factor | ------71 | |
Delivery information | ||
Export Control Regulations | ECCN : N / AL : N | |
Estimated dispatch time (Working Days) | 100 Day/Days | |
Net Weight (kg) | 11,503 Kg | |
Package size unit of measure | Not available | |
Quantity Unit | 1 Piece | |
Packaging Quantity | 1 | |
Additional Product Information | ||
EAN | Not available | |
UPC | 662643366662 | |
Commodity Code | 85015220 | |
LKZ_FDB/ CatalogID | SD.NC60KT-1FK7 | |
Product Group | 5684 | |
Group Code | R2S3 | |
Country of origin | Germany | |
Compliance with the substance restrictions according to RoHS directive | Since: 22.07.2017 | |
Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. | |
WEEE (2012/19/EU) Take-Back Obligation | Yes | |
REACH Art. 33 Duty to inform according to the current list of candidates |
|
|
SCIP number | Not available |
