OMRON NS8-TV00-V2

Yeni

OMRON NS8-TV00-V2

NS8-TV00-V2 omron NS8-TV00-V2 NS15/NS12/NS10/NS8 Tek dokunuşla makine yönetimi NS serisi, 5,7 inç Tek Renkli STN'den 15 inç TFT'ye kadar geniş bir ürün yelpazesini kapsayan gelişmiş HMI serimizdir. Kolayca programlanan bu ürün birden fazla iletişim olanağı, PLC'lerimiz ve Ladder monitörlü diğer cihazlarla iyi bir uyum, Akıllı Aktif Parçalar ve başarısı kanıtlanmış güvenilirlik gibi gelişmiş özellikler sunar. Mükemmel netlik ve hızlı değişen ekranlar Son derece uzun arka ışık ömrü (50.000 saate kadar) Tüm Avrupa dilleri, Asya ve Kiril dilleri için destek Kompakt flaşta kolay veri depolama Geniş Hafıza boyutu (60 MB) Belirli OMRON harici PLC'ler için destek

Kategori :: Omron
Ürün Kodu :: NS8-TV00-V2 omron
Etiketler :: OMRON NS8-TV00-V2 omron https://www.yapmuh.com/omron-ns8-tv00-v2.html , OMRON NS8-TV00-V2 , NS8-TV00-V2 , NS8-TV00-V2 ekran , NT11S EKRAN , NB EKRAN , NT21 EKRAN , NA EKRAN , NQ5 EKRAN
Stok :: Stokta Var

Açıklama
Sipariş Formu

Mükemmel netlik ve hızlı değişen ekranlar
Son derece uzun arka ışık ömrü (50.000 saate kadar)
Tüm Avrupa dilleri, Asya ve Kiril dilleri için destek
Kompakt flaşta kolay veri depolama
Geniş Hafıza boyutu (60 MB)
Belirli OMRON harici PLC'ler için destek

Özellikler ve sipariş bilgisi

Ordering information

Type			Order Code
TFT, 15", 1024 x 768 pixels	with Ethernet	Black	NS15-TX01B-V2
TFT, 15", 1024 x 768 pixels	with Ethernet	Silver	NS15-TX01S-V2
TFT, 12", 800 x 600 pixels	no Ethernet	Black	NS12-TS00B-V2
	no Ethernet	Ivory	NS12-TS00-V2
	with Ethernet	Black	NS12-TS01B-V2
	with Ethernet	Ivory	NS12-TS01-V2
TFT, 10", 640 x 480 pixels	no Ethernet	Black	NS10-TV00B-V2
	no Ethernet	Ivory	NS10-TV00-V2
	with Ethernet	Black	NS10-TV01B-V2
	with Ethernet	Ivory	NS10-TV01-V2
TFT, 8.4", 640 x 480 pixels	no Ethernet	Black	NS8-TV00B-V2
	no Ethernet	Ivory	NS8-TV00-V2
	with Ethernet	Black	NS8-TV01B-V2
	with Ethernet	Ivory	NS8-TV01-V2

Note: For the accessories, please refer to

Specifications

Item	NS15	NS12	NS10	NS8
Display type	15 inch color TFT	12 inch color TFT	10 inch color TFT	8 inch color TFT
Display resolution	1024×768 (XGA)	800×600 (SVGA)	640×480 (VGA)
Number of colors	256 (32.768 for image data)
Backlight	2×CCFL	1×LED
Backlight lifetime	Min. 50000 hours
View angle	Left/right ±85°, Top 70°, Bottom 80°	Left/right ±60°, Top 45°, Bottom 75°	Left/right ±60°, Top 35°, Bottom 65°	Left/right ±65°, Top 50°, Bottom 60°
Touch panel	Analog resistive touch	Matrix resistive touch
Number of functional keys	3	-
Dimensions in mm (H×W×D)	304×405×75.8	241×315×48.5		177×232×48.5
Weight	4.2 kg max.	2.5 kg max.		2.0 kg max.
Screen data capacity	60 MB
Internal memory	Bit memory: 32,767 bits, Word memory: 32,767 words, Retentative memory: 8,192 bits and 8,192 words.
Memory card interface	1 slot ATA Compact Flash card
Printer connection	PictBridge support
Serial (COM1)	1×RS-232
Serial (COM2)	1×RS-232/422/485	1×RS-232
USB Slave	For programming & printing
Ethernet	IEEE 802.3u 10Base-T/100Base-TX
Expansion module	Optional network/video unit			Optional video unit
Line voltage	24 VDC ±15%
Power consumption	45 W max.	25 W max.
Battery	CJ1W-BAT01
Battery lifetime	5 years (at 25°C)
Enclosure rating (front side)	IP65F (equivalent to NEMA4)
Obtained standards	UL 1604 Class 1 Diff. 2, cUL, CE, Lloyds, DNV
Operating environment	No corrosive gases
Noise immunity	Conforms to IEC61000-4-4, 2 KV (power lines)
Ambient operating temperature	0 to 50°C 1
Ambient operating humidity	35% to 85% (0 to 40°C) with no condensation, 35% to 60% (40 to 50°C) with no condensation

Aksesuarlar

Ordering information

Type	Description		Order code
Cable	Serial programming cable		XW2Z-S002
Cable	USB programming cable, 2 m		CP1W-CN221
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 2 m	XW2Z-200T
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 5 m	XW2Z-500T
Accessories	Video input	Inputs: 4 channels NTSC / PAL	NS-CA001
	Video input	Inputs: 2 channels NTSC / PAL, 1 channel RGB	NS-CA002
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (2 m)
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (5 m)
	Controller link interface unit		NS-CLK21
	RS-422A/485 adapter (50 m)		CJ1W-CIF11
	RS-422A adapter (500 m)		NS-AL002
	Anti-reflection sheets (5 sheets)	NS15	NS15-KBA04
		NS12/10	NS12-KBA04
		NS8	NS7-KBA04
		NS5	NT30-KBA04
	Anti-reflection protective covers (5 pack)	NS12/10	NS12-KBA05
		NS8	NS7-KBA05
		NS5	NT31C-KBA05
	Transparent protective covers (5 pack)	NS15 (1 cover)	NS15-KBA05N
		NS12/10	NS12-KBA05N
		NS8	NS7-KBA05N
		NS5	NT31C-KBA05N
	Chemical-resistant cover (1 cover)	NS5	NT30-KBA01
	Attachment adapter	(NT625C/631/631C series to NS12 series)	NS12-ATT01
		(NT625C/631/631C series to NS12 series) Black	NS12-ATT01B
		(NT620S/620C/600S series to NS8 series)	NS8-ATT01
		(NT600M/600G/610G/612G series to NS8 series)	NS8-ATT02
	Memory card	128 MB	HMC-EF183
		256 MB	HMC-EF283
		512 MB	HMC-EF583
	Memory card adapter for PC		HMC-AP001
	Battery		CJ1W-BAT01
